Ambient
operating temperature |
10~40℃ |
|
Maximum enclosure temperature
|
55℃ |
|
Input
line voltage |
100~240 VAC |
|
Input line frequency |
50~60 Hz |
|
Power
consumption |
65 Watts max. |
|
Output power |
50 Watts max. |
|
Output
frequency |
470KHz |
|
Power code(3-wire) |
183cm |
|
Power
supply dimension |
W122×D200×H152.5mm |
|
Agency tested per |
IEC61000-6-1,EC61000-6-3 &
UL499,FCC CFR Part15 |
|
Tip-to-ground
potential |
2mV |
|
Tip-to-ground resistance |
2ohms |
|
Idle tip
temperature stability |
1.1℃ In still
air |
|
Hand-piece cable length
|
L : 710mm burn proof, ESD safe |
|
Hand-piece
cable connector |
8-pin power
connector |
|
Workstand supply dimension |
W100×D200×H100mm |
